SMARTIA VS67
We believe that excellence is not an option. It is an Attitude.
Information
SMARTIA VS67 is the new complete Tilt & Turn system of ALUMIL, which combines outstanding thermal insulation performances along with high construction flexibility and exceptional design.
Advantages
- Very good value for money
- High energy savings due to the high energy efficiency of the system
- Increased level of security
- High level of sound insulation
- Ease of use and high functionality
- Modern design for windows either with flat or curved line
- Ease of access according to specifications for people with special needs and children
- High quality with certified performances
- Increased static loads and functionality in case of severe weather conditions
Specifications
WINDOW TYPE
Hinged
THERMAL INSULATION
Yes
EXTERIOR SHAPES
Flat
UF
from 1,1 to 2,6 W/m²K
FRAME DEPTH
67 mm
SASH DEPTH
75 mm
MINIMUM VISIBLE ALUMINIUM FACE HEIGHT
93 mm
MINIMUM VISIBLE ALUMINIUM FACE WIDTH AT THE CENTRAL VERTICAL COLUMN (ADJOINING PROFILE)
67 mm
GLAZING TYPE
Double - Triple
MAXIMUM GLAZING THICKNESS
up to 58 mm
MECHANISM
Euro-groove, Euro-nut
SEALING METHOD
Perimetrical at 3 levels with EPDM gaskets
MINIMUM THRESHOLD HEIGHT
13 mm
TYPE OF THERMAL INSULATION
30mm fiber glass polyamides, PE insulation Foam
WATER TIGHTNESS
CLASS Ε1200
AIR PERMEABILITY
CLASS 4
WIND LOAD RESISTANCE
Class: C5
SOUND REDUCTION
45 dB
BURGLAR RESISTANCE
RC2/RC3
SASH WEIGHT
up to 180 Kg
