SUPREME VSD95
We believe that excellence is not an option. It is an Attitude.
Information
The system SUPREME VSD95 belongs to ALUMIL’s series for entrance doors with high quality standards. The system includes a complete range of thermal break profiles with flat design for totally aligned constructions that offer high functionality. Offering many infill options including aluminium or glass panels, the SUPREME VSD95 is able to meet the most demanding architectural trends and aesthetics.
Advantages
- High energy savings thanks to high energy efficiency
- High security level
- Modern design
- Ease of access, ideal for people with special needs and children
- Exceptional sound insulation
- Ease of use and high functionality
- Wide variety of typologies and solutions
- Exceptional quality with certified performances
Specifications
THERMAL INSULATION
Yes
EXTERIOR SHAPES
Flat
FRAME DEPTH
95 mm
GLAZING TYPE
Double – Triple
MAXIMUM GLAZING THICKNESS
24 up to 54 mm
MECHANISM
Perimetrical locking mechanism
SEALING METHOD
Perimetrical at 3 levels with EPDM gaskets
MINIMUM THRESHOLD HEIGHT
22 mm
TYPE OF THERMAL INSULATION
Polyamides 34 mm width, ALUMIL Energy bar, Insulation foam
TYPES OF TYPOLOGY
For all entrance door typologies with glass or aluminium panels
BURGLAR RESISTANCE
RC3
AIR PERMEABILITY
CLASS 4
WIND LOAD RESISTANCE
C5/B5
SASH WEIGHT
up to 180 Kg
UF
from 1,2 up to 2,1 W/m²K
MINIMUM VISIBLE ALUMINIUM FACE HEIGHT
122 mm
